14.4V-3A C45 LiFePO4 Battery charger
10Years Warranty
20Years of Design Life
16 Units Flexible Capacity Expansion
Easy Installation: Wall Mounted
Intelligent BMS:Multiple Safe Protections
High Compatibility:Compatible with Many Brands of Inverters
| System Specification | |
| Model | RBmax5.1L-F |
| Electric Data |
|
| Nominal Energy (kWh) | 5.12 |
| Usable Energy (kWh) | 4.79 |
| Cell Type | LFP (LiFePO4) |
| Nominal Voltage (V) | 51.2 |
| Operating Voltage Range (V) | 44.8 ~ 56.8 |
| Max. Continuous Charge Current (A) | 100 |
| Max. Continuous Discharge Current (A) | 100 |
| General Data | |
| Weight (Kg / lbs.) | 48 Kg / 105.8 lbs. |
| Dimensions (W × D × H) (mm / inch) | 500 x 167 x 490 mm / 19.69 x 6.57 x 19.29 inch |
| Operating Temperature (°C) | 0 ~ 55℃ (32 ~ 131℉) (Charge), -20 ~ 55℃ (4 ~ 131℉) (Discharge） |
| Storage Temperature (°C) Delivery SOC State (20~40%) |
>1 Month: 0 ~ 35℃ (32 ~ 95℉); ≤1 Month: -20 ~ 45℃ (-4 ~ 113℉) |
| Relative Humidity | ≤ 95% |
| Max. Altitude (m) | 4000 m / 13,123 ft (＞2,000 m / ＞6,561.68 ft derating） |
| Protection Degree | IP 20 |
| Installation Location | Ground-Mounted; Wall-Mounted |
| Communication | CAN, RS485 |
| Certification | EM,CE,Transportation,UN38.3 |
| Warranty | |
| Warranty (Years) | 5 Years |
| System Specification | |
| PV (DC Input) | |
| Recommended Max. PV Input Power | 6000W |
| Max. Input Voltage (VOC) | 500V |
| MPPT Operating Voltage Range | 85V-450V (@75V Start up) |
| Number of MPPT | 1 |
| Max. Number of Input Strings per MPPT | 1 |
| Max. Input Current per MPPT | 27A |
| Max. Short-circuit Current per MPPT | 35A |
| Grid (AC Input) | |
| Max. Input Power | 11500W |
| Max. Input Current | 50A |
| Rated Grid Voltage | 220 / 230 / 240Vac |
| Rated Grid Frequency | 50 / 60Hz |
| Acceptable Range | 170-280Vac (For UPS); 90-280Vac (For Home Appliances) |
| Battery (Bi-direction) | |
| Battery Type | LiFePO4 / Lead-acid |
| Battery Voltage Range | 40-60Vdc |
| Rated Battery Voltage | 48Vdc |
| Max. Charge / Discharge Current | 120A / 130A |
| BMS Communication Mode | RS485 |
| Efficiency | |
| Peak Efficiency | 0.98 |
| Max. MPPT Efficiency | 0.999 |
| Backup Output (AC Output) | |
| Rated Output Power | 6000W / 6000VA |
| Rated Output Current | 27.3A |
| Rated Output Voltage / Frequency | 220 / 230 / 240Vac 50 / 60Hz |
| Parallel Capacity | Max. 12 Units |
| Surge Power | 12000VA 5s |
| THDv (@ Linear Load) | ＜3% |
| Switch Time | 10ms Typical (For UPS), 20ms Typical (For Home Appliances) |
| Protection | |
| Inner Protection | Output Short-circuit Protection, Output Overvoltage Protection |
| Surge Protection | PV: Type III, AC: Type III |
| IP Rating | IP54 |
| General Specifications | |
| Operating Temperature Range | -10℃~55℃ |
| Relative Humidity Range | 5%~95% |
| Max. Operating Altitude | ＞2000m Derating |
| Standby Self-consumption | ＜10W |
| Installation Type | Wall-mounted |
| Cooling Mode | Fan Cooling |
| Communication | RS232/RS485/Dry Contact/Wi-Fi |
| Display | LCD |
| Mechnical Specifications | |
| Inverter Dimension (L x W x H) | 346.6 x 120 x 444.7 mm |
| Shipping Dimension | 560 x 465 x 240mm |
| Net Weight | 12.4kg |
| Gross Weight | 14.6kg |
| Warranty Period | 3 Years |
